Supported Platforms
160
Table 10 lists the optional expansion modules supported by the
software.
Table 10 Optional Expansion Modules
Model
Number
of Ports
Type of Ports
Type of
Connector Type of
Cable
1
Maximum
Distance
2
AT-A14 1 100/1000Base-T RJ-45 Category 5 or
better twisted
pair
3
100 m (328 ft)
AT-A15/SX 1 1000Base-SX SC Multimode
fiber optic 550 m (1,804 ft)
AT-A15/LX 1 1000Base-LX SC Single-mode
fiber optic 10 km (6.2 mi)
AT-A16 2 100Base-FX VF-45 Multimode
fiber optic 2 km (1.25 mi)
AT-A17 2 100Base-FX SC Multimode
fiber optic 2 km (1.25 mi)
AT-A18 4 10/100Base-TX RJ-45 Category 3
(for 10Base-T)
or Category 5
(for 100Base-
T) or better
twisted pair 100 m (328 ft)
AT-A19 2 100Base-FX MT-RJ Multimode
fiber optic 2 km (1.25 mi)
AT-A22/SX 1 1000Base-SX SC Multimode
fiber optic 550 m (1,804 ft)
AT-A22/LX 1 1000Base-LX SC Single-mode
fiber optic 10 km (6.2 mi)
1. Multimode fiber optic cable can be either 50/125µm or 62.5/125µm cabling. Single-mode fiber optic cable must be 9/125µm
2. Maximum distance can be less depending on the duplex mode of the end node and the type of cabling used with the module.
3. Contact a qualified cabling technician for details on the IEEE specifications for Gigabit Ethernet over twisted
pair cabling.
