Getting Started
34
Menu Tree
Table 3 lists the Omega menu selections.
Table 3 Omega Menu Selections
Main Menu
Selection
Menu Selection Page Function
Port Status and Configuration
Port number 66, 68 Displays and configures the parameter
settings for the ports on the switch.
Ethernet Statistics
Transmit statistics 137 Displays statistics on the number of
frames transmitted by a port or the
switch.
Individual port
overview 134,
137 Displays the received and transmitted
frame statistics for a specific port.
RMON statistics 139 Displays RMON statistics for the entire
switch.
Port RMON statistics 140 Displays RMON statistics by port.
Zero all statistic
counters on the entire
system 141 Returns the statistic counters in a switch
to 0 (zero).
Administration
XModem software
update to this system 150 Downloads the AT-S24 software onto the
switch using XModem. Only available via a
local Omega session.
Connect to a remote
system 33 Enables you to connect to and manage
another switch while running a local
management session on a switch. Only
available via a local Omega session.
Ping a remote system 62 Tests the connectivity to another network
node.
Activity monitor 61 Displays the switch’s activity monitor.
Diagnostics 59 Performs a series of diagnostic tests on
the switch.
