Configuring Virtual LANs and Quality of Service
126
Figure 53 illustrates a network that uses several AT-8224XL Switches and
an AT-9006SX/SC Switch to provide individual end nodes access to a
WAN. The example shows three AT-8224XL Switches, each of which is
operating in the multiple VLAN mode.
Figure 59 Example Topology Using the Multiple VLAN Mode
