SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide
Section II: Installing the Chassis
157
Figure 97. Installing a Transceiver in the AT-SBx81XS16 Line Card
Note
If you are ready to attach the fiber optic cable to the transceiver,
continue with the next step. Otherwise, repeat steps 1 to 2 to install
the remaining SFP transceivers in the line cards.
3. Remove the protective cover from the SFP+ transceiver, as shown in
Figure 98. Removing the Dust Cover from a Transceiver in the AT-
SBx81XS16 Line Card
Handle
