Installing the AT-SBxPWRPOE1 PoE Power Supply
This section contains the installation procedure for the AT-SBxPWRPOE1
Power Supply, for the PoE+ ports on the AT-SBx81GP24 PoE Line Card.
For background information, refer to “AT-SBxPWRPOE1 Power Supply”
on page 30.
Caution
The electronic components in the AT-SBxPWRPOE1 PoE Power
Supply can be damaged by electro-static discharges (ESD). Follow
the procedure in “Protecting Against Electrostatic Discharge (ESD)”
on page 106 to guard against ESD damage when unpacking and
installing the power supply.
To install the power supply, perform the following procedure:
1. Choose a slot for the AT-AT-SBxPWRPOE1 System Power Supply in
the chassis.
You may install it in either slot A or B, shown in Figure 44 on page 107.
2. Raise the handle on the blank panel covering the selected slot and
slide the panel from the chassis. Figure 51 on page 114 illustrates the
removal of the blank panel from slot A.
