Chapter 6: Installing the Power Supplies
122 Section II: Installing the Chassis
Figure 59. On/Off Switch on the AT-SBxPWRSYS1 DC Power Supply
5. With a #2 Phillips-head screwdriver, loosen the handle locking screw
on the power supply, as shown in Figure 60.
Figure 60. Loosening the Handle locking Screw on the AT-SBxPWRSYS1
DC System Power Supply
6. Raise the locking handle on the power supply, as shown Figure 61 on
page 123.
On/Off
Switch
