SwitchBlade x8106 Chassis Switch and AT-SBx81CFC960 Card Installation Guide
Section I: Hardware Overview 61
Slots for 10Gbps SFP+
Transceivers Supports four 10Gbps SFP+ transceivers
for uplink ports for the Ethernet line cards
or AT-Stack transceivers for the VCStack
Plus feature. The transceivers are ordered
separately. For a list of supported
transceivers, refer to the Allied Telesis
web site. For more information, refer to
“SFP+ Slots” on page 70.
Console RS-232 Port Provides local management of the switch.
The switch does not require an IP address
for local management. For more
information, refer to “Console (RS-232)
Port” on page 72.
NET MGMT (eth0) Port Provides maintenance access to the
controller card. For more information, refer
to “Ethernet Management Port (NET
MGMT)” on page 73.
USB Port Used with a USB flash memory drive for
management functions, such as storing
backup copies of the switch configuration
and transferring configurations between
switches. For more information, refer to
“USB Port” on page 75.
Reset Button Resets the controller and Ethernet line
cards. For more information, refer to
“Reset Button” on page 76.
Table 16. Components on the AT-SBx81CFC960 Controller Fabric Card
Component Description
