SwitchBlade x8106 Chassis Switch and AT-SBx81CFC960 Card Installation Guide
Section I: Hardware Overview 55
Automatic MDIX
Detection
The 10/100/1000 Mbps twisted-pair ports on the AT-SBx81GT24, AT-
SBx81GT40, and AT-SBx81GP24 Line Cards are IEEE 802.3ab compliant
and feature automatic MDIX detection when operating at 10 or 100 Mbps.
(Automatic MDIX detection does not apply to 1000 Mbps.) This feature
automatically configures the ports to MDI or MDI-X depending on the
wiring configurations of the end nodes.
Ports connected to network devices that do not support automatic MDIX
detection default to MDIX.
You may disable automatic MDIX detection on the individual ports and
configure the MDI/MDI-X settings manually with the POLARITY command.
Port Pinouts Refer to Table 40 on page 319 for the pinouts of the twisted-pair ports
when they operate at 10 or 100 Mbps in the MDI configuration and
Table 41 on page 319 for the MDI-X configuration. For the port pinouts
when they operate at 1000 Mbps, refer to Table 42 on page 320.
Standard TIA/EIA 568-
A-compliant Category 5
shielded or unshielded
cabling with 100 ohm
impedance and a
frequency of 100 MHz. Yes Yes No Yes Yes No Yes No No
Standard TIA/EIA 568-
B-compliant Enhanced
Category 5 (Cat 5e)
shielded or unshielded
cabling with 100 ohm
impedance and a
frequency of 100 MHz. Yes Yes Yes Yes Yes Yes Yes Yes Yes
Standard TIA/EIA 568-
B-compliant Category 6
or 6a shielded cabling. Yes Yes Yes Yes Yes Yes Yes Yes Yes
Table 13. Twisted Pair Cable for the AT-SBx81GP24 Line Card (Continued)
Cable Type
10Mbps 100Mbps 1000Mbps
Non-
PoE
PoE PoE+
Non-
PoE
PoE PoE+
Non-
PoE
PoE PoE+
