Appendix A
Technical Specifications
Physical Specifications
Dimensions (W x D x H)
Weight (Kilograms)
Table 26. Product Dimensions
AT-SBx8106 Chassis
48.03 cm x 38.79 cm x 17.63 cm
18.91 in x 15.27 in x 6.94 in)
AT-SBxPWRSYS1 AC System
Power Supply
10.16 cm x 32.21 cm x 4.34 cm
(4.00 in x 12.68 in x 1.71 in)
AT-SBxPWRPOE1 PoE Power
Supply
10.16 cm x 32.21 cm x 4.34 cm
(4.00 in x 12.68 in x 1.71 in)
AT-SBxPWRSYS1 DC System
Power Supply
10.16 cm x 34.2 cm x 4.34 cm
(4.00 in x 13.46 in x 1.71 in)
AT-SBxFAN06 Tray Module
2.62 cm x 29.81 cm x 10.30 cm
(1.03 in x 11.73 in x 4.05 in)
All Cards
AT-SBx81GT24 Line Card
AT-SBx81GT40 Line Card
AT-SBx81GP24 PoE Line Card
AT-SBx81GS24a SFP Line Card
AT-SBx81XS6 SFP+ Line Card
AT-SBx81XS16 SFP+ Line Card
AT-SBx81CFC960 Controller
Fabric Card
20.67 x 31.32 cm x 4.06 cm
(8.14 in x 12.33 in x 1.6 in)
Table 27. Product Weights
AT-SBx8106 Chassis
14.42 kg (31.80 lb) with three PSU
and six line card blank panels
AT-SBx81GT24 Line Card
0.93 kg (2.05 lb)
AT-SBx81GT40 Line Card
1.04 kg (2.30 lb)
