Figure 39: installing the rack mount screws – Allied Telesis AT-SBx81CFC960 User Manual
Page 102
Chapter 5: Installing the Chassis in an Equipment Rack
102
Section II: Installing the Chassis
Figure 39. Installing the Rack Mount Screws
5. Tighten all six screws shown in Figure 40 on page 103 to secure the
chassis to the equipment rack, Allied Telesis recommends tightening
the screws to 10 inch-lbs.
Screws
Screws
