SwitchBlade x8106 Chassis Switch and AT-SBx81CFC960 Card Installation Guide
Section II: Installing the Chassis 121
Installing the AT-SBxPWRSYS1 DC System Power Supply
This section contains the installation procedure for the AT-SBxPWRSYS1
DC Power Supply. For background information, refer to “AT-
SBxPWRSYS1 DC Power Supply” on page 32.
Caution
The electronic components in the AT-SBxPWRSYS1 DC Power
Supply can be damaged by electro-static discharges (ESD). Follow
the procedure in “Protecting Against Electrostatic Discharge (ESD)”
on page 108 to guard against ESD damage when unpacking and
installing the power supply.
To install the power supply, perform the following procedure:
1. Choose a slot in the chassis for the AT-AT-SBxPWRSYS1 DC System
Power Supply.
You may install it in slot C or D, shown in Figure 47 on page 109. The
first AT-SBxPWRSYS1 Power Supply should be installed in slot D,
because the slot does not have a blank power supply panel.
Caution
The AT-SBxPWRSYS1 DC System Power Supply will not work in
slot A or B.
2. If the chassis already has a power supply in slot D, remove the blank
power supply panel from slot C by lifting the blank panel handle and
sliding it out of the slot, as shown in Figure 60 on page 122.
