Chapter 8: Installing the Transceivers and Cabling the Ports

146

Section II: Installing the Chassis

Figure 84. Connecting Cables to Ports on the AT-SBx81GT40 Line Card

Release tab

Connecting a cable to a port
in the top row.

Connecting a cable to a port
in the bottom row.
