Allen-Bradley 1336-Series AC Drives
97 F232120 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Wire
During troubleshooting, if the wire path between the
control board and the drive is uncertain, refer to
Table 55 for wire connection numbers.
Control Wire Connection Reference Table.
Table 55
Output Board Terminal
V-Control F370314, F8206501 and F370447-6, etc.
STF 19
STR 22
RH 28
RM 27
RL 26
COM 29
WE-6 Interface Board P/N: F370577, F0370446-xx
J2A-30 29
J2A-31 27
J2A-32 19
J2A-33 26
J2A-34 28
J2A-35 22
UniLinc Control– Output Board F8108001
H13-2 29
H13-3 28
H13-4 27
H13-5 26
H13-6 22
H13-7 19
