Allen-Bradley 1305-Series AC Drives
79 F232120 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Displaying Linear List of Parameters
1. Install the HIM on the A-B drive.
2. Turn on machine power.
3. After three to five seconds of initialization,
display will show the status display. If drive is in
a faulted condition, fault will appear in display;
otherwise, drive will read current status. Refer to
examples below.
4. Press any key to enter Mode Level,
. Display will read:
5. Use the Up and Down arrow keys to
select “Display” if not displayed immediately.
6. Press the Enter key to choose Group Level.
Display will read:
For earlier HIM versions, press the Enter key
to choose Main File. Display will read:
7. Use the Up and Down arrow keys to
select “Linear List.”
8. Press the Enter key to choose Parameter
Level. Display now shows all parameters in
numerical order.
9. Use the Up and Down arrow keys to
select desired parameter display.
10. From this point, press the Escape key to
move display up one Level (i.e., press the Escape
key three times to return to Operator Level).
Faulted Drive Normal Condition
Examples of Faults Example of Normal
Condition
Fault Description
Fault Number Status of Drive
Frequency Commanded
Max Retries Fault
F 33
Serial Fault
F 10 Stopped
+0.00 Hz
ESC SEL
.
Choose Mode
Display
.
Choose Group
Linear List
Linear List
Main File
Output Voltage
0 Vlts 1
ESC
