Alliance Laundry Systems 160 User Manual
Page 23
PowerFlex 40 and 400 Drive Control Logic
21
F232120
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Figure 16
PHM738N
Figure 15
PHM776N
P/N: F8108001 UniLinc Output Board
Drive
Harness
Connection
H13
16
9
8
1
UNILINC, QUANTUM, GALAXY AND UNIMAC SOFTWARE OUTPUT BOARD
PHM776N
A AND B-CONTROL OUTPUT BOARD
Drive Harness
Connection J11
