Viewing a Display Group
(Parameters #1 – 16 for Series A & B or
Parameters #1 – 19 for Series C)
1. Install PKM on A-B 160 drive. Refer to
“Installation/Removal”.
2. Turn on machine power.
3. Select the desired parameter by pressing the Up
and Down arrow keys . The parameter
value is shown in the last four digits of the
display.
Viewing a Program Group
(Parameters #30 – 80 for Series A & B or
Parameters #30 – 86 for Series C)
1. Install PKM on A-B 160 drive. Refer to
“Installation/Removal.”
2. Turn on machine power.
3. The PKM begins in Display. Press the ESC key
to enter the Program Group.
NOTE: Confirmation of the mode is presented by a
decimal point after the second parameter digit.
4. Parameter #30 should be displayed if entering the
program group for the first time.
5. From this point, parameters #30 – 80 can be
viewed by pressing the Up and Down arrow keys
.
6. To exit the Program Group, press the
ESC key .
Display Mode Parameter Set
0 1 0. 0
3 0. 5. 0
CAUTION
Users are prohibited from changing
parameter values unless specifically
instructed by the washer-extractor
manufacturer. Modification to parameter
values may present potential harmful
operating conditions for both hardware and
personnel.
W673
ESC
ESC
1 Output Frequency
2 Output Voltage
3 Output Current
4 Output Power
5 Bus Voltage
6 Frequency Command
7 Last Fault
8 Heatsink Temperature
9 Controller Status
10 Controller Type
11 Control Version
12 Input Status
13 Power Factor Angle
14 Memory Probe Address
15 Preset Status
16 Balance Angle
*17 Fault Buffer 0
*18 Fault Buffer 1
*19 Fault Buffer 2
Table 33
