PowerFlex 40 and 400 Drive Control Logic
F232120 16 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
PowerFlex 40 Drive Control Logic Chart
Pocket Hardmount
“V” control and “A” control - Designs 7 and 8
H – Signal Voltage High (approximately 24V DC)
L – Signal Voltage Low (less than 1V DC) 0 = No signal received
1 = Signal received
Digital
In 3
Digital
In 2
Digital
In 1
Stop Rev Fwd
Digital Input
Status – Parameter
d014
Control Input
Status – Parameter
d013
DC Volt Meter Red Probe Terminal Location 07 06 05 01 03 02
DC Volt Meter Black Probe Terminal Location 04 04 04 04 04 04
Action
Frequency
Preset
Parameter #
Terminal
#07
(SW3)
Terminal
#06
(SW2)
Terminal
#05
(SW1)
Terminal
#01
(Stop)
Terminal
#03
(STR)
Terminal
#02
(STF)
*Di
g
it
a
l
In
4
Digi
ta
l In 3
(SW3)
Digi
ta
l In 2
(SW2)
Digi
ta
l In 1
(SW1)
DB T
rans
On
St
o
p
Rev (STR) Fw
d (STF)
Idle N/A H H H L/H H H 0 0 0 0 0 0/1 0 0
1/2 Wash Speed Forward 71 H H L L H L *1 0 0 1 0 1 0 1
1/2 Wash Speed Reverse 71 H H L L L H 0 0 0 1 0 1 1 0
Wash Speed Forward 72 H L H L H L *1 0 1 0 0 1 0 1
Wash Speed Reverse 72 H L H L L Ha 0 0 1 0 0 1 1 0
Distribution Speed 74 L H H L H L *1 1 0 0 0 1 0 1
Spin 1 Extract 73 H L L L H L *1 0 1 1 0 1 0 1
Spin 2 Extract 76 L L H L H L *1 1 1 0 0 1 0 1
Spin 3 Extract 75 L H L L H L *1 1 0 1 0 1 0 1
*If digital in 4 is wired to the Forward Input terminal #02, this input will be a “1” whenever the drive receives a forward command. Disregard otherwise.
Pocket Hardmount
WE-6 control - Design 5 and Earlier
H – Signal Voltage High (approximately 24V DC)
L – Signal Voltage Low (less than 1V DC) 0 = No signal received
1 = Signal received
Digital
In 3
Digital
In 2
Digital
In 1
Stop Rev Fwd
Digital Input
Status – Parameter
d014
Control Input
Status – Parameter
d013
DC Volt Meter Red Probe Terminal Location 07 06 05 01 03 02
DC Volt Meter Black Probe Terminal Location 04 04 04 04 04 04
Action
Frequency
Preset
Parameter #
Terminal
#07
(SW3)
Terminal
#06
(SW2)
Terminal
#05
(SW1)
Terminal
#01
(Stop)
Terminal
#03
(STR)
Terminal
#02
(STF)
*D
ig
it
a
l In
4
D
igit
a
l In 3
(SW3)
D
igit
a
l In 2
(SW2)
D
igit
a
l In 1
(SW1)
DB T
rans
On
St
o
p
Rev (STR) Fw
d (STF)
Idle N/A H H H L/H H H 0 0 0 0 0 0/1 0 0
1/2 Wash Speed Forward 74 L H L L H H *1 1 0 0 0 1 0 1
1/2 Wash Speed Reverse 74 L H H L L H 0 1 0 0 0 1 1 0
Wash Speed Forward 72 H L H L H H *1 0 1 0 0 1 0 1
Wash Speed Reverse 72 H L H L L H 0 0 1 0 0 1 1 0
Distribution Speed 71 H H L L H L *1 0 0 1 0 1 0 1
Medium Extract/Spray Rinse 76 L L H L H H *1 1 1 0 0 1 0 1
High 1 Extract 75 L H H L H L *1 1 0 1 0 1 0 1
High 2 Extract 73 H L L L H L *1 0 1 1 0 1 0 1
High 3 Extract 77 L L L L H L *1 1 1 1 0 1 0 1
*If digital in 4 is wired to the Forward Input terminal #02, this input will be a “1” whenever the drive receives a forward command. Disregard otherwise.
