Selecting a Parameter
There are two methods for selecting and viewing
Display and Program Group parameters: scrolling
through the parameters or entering the parameter
number with the numeric keypad.
Scroll Parameter List
1. Connect CopyCat Keypad to Drive. Refer to
“Installation/Removal” in this section.
2. Turn on machine power.
3. For Display Group parameters (#1 – 19), press
the Escape key until the Program LED and
Load LED are both off; for Program Group
parameters (#30 – 86), press the Escape key until
the Program LED lights.
4. Press the Up or Down arrow key to
scroll to the next or previous parameter. Press
and hold the Up or Down arrow key to increase
scrolling speed.
Enter Parameter Number
1. Connect CopyCat Keypad to Drive. Refer to
“Installation/Removal”.
2. Turn on machine power.
3. For Display Group parameters (#1 – 19), press
the Escape key until the Program LED and
Load LED are both off; for Program Group
parameters (#30 – 86), press the Escape key until
the Program LED lights.
4. Enter the desired two-digit parameter number
using the numeric keys.
The display shows the parameter number entered.
For example: >17.
To correct an entry, press the Delete
key .
5. Press the Enter key , and the newly selected
parameter name, number and value are displayed.
If the parameter number entered does not exist, an
error message is displayed
.
6. Press the Enter key or the Escape key
to return to the previous parameter.
NOTE: Ensure the parameter to be displayed is in
the group that is currently being displayed: Display
Group (#1 – 19) or Program Group (#30 – 86).
Refer to Step 3.
ESC
ESC
Output Current
P-03: 0.00 >17
DEL
Fault Buffer 0
P-17: Under Volt
ERROR, No
Parameter P-33
ESC
