Allen-Bradley 160-Series AC Drives
F232120 50 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Wire
During troubleshooting, if the wire path between the
control board and the drive is uncertain, refer to
Table 32 for wire connection numbers.
Control Wire Connection Reference Table.
Table 32
Output Board Terminal
V-Control F370314, F8206501 and F370447-6, etc.
STF 6
STR 5
RH 4
RM 2
RL 1
COM 3
WE-6 Interface Board P/N: F370577, F0370446-xx
J2A-30 3
J2A-31 2
J2A-32 6
J2A-33 4
J2A-34 1
J2A-35 5
EDC – Output Board P/N: F370433
H2-7 4
H2-8 2
H2-9 1
H2-10 3
H2-11 5
H2-12 6
Table 32 (continued)
Table 32 (continued)
Output Board Terminal
A and B-Control P/N: F0370448xx
J11-1-8/STF 6
J11-1-7/STR 5
J11-1-6/RH 4
J11-1-5/RM 2
J11-1-4/RL 1
J11-1-3/COM 3
PS40 Main Board P/N: C000281
C12 OV, R-, L- 3
C12 0-10v 2
C12 R+ 6
C12 L+ 5
Jumper 7 and 8
