Allen-Bradley 1305-Series AC Drives
F232120
72
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Wire
During troubleshooting, if the wire path between the
control board and the drive is uncertain, refer to
Table 44 for wire connection numbers.
Control Wire Connection Reference Table.
Table 44
Output Board Terminal
V-Control F370314, F8206501 and F370447-6, etc.
STF
6
STR
13
RH
18
RM
17
RL
16
COM
7
WE-6 Interface Board P/N: F370577, F0370446-xx
J2A-30
7
J2A-31
17
J2A-32
6
J2A-33
18
J2A-34
16
J2A-35
13
EDC – Output Board P/N: F370433
H2-7
18
H2-8
17
H2-9
16
H2-10
7
H2-11
13
H2-12
6
