3-12
Maintain the ink system
HP Designjet 5100 printer Customer Reference Guide
service station, in the direction indicated by the arrow shown here.
2 When the printhead cleaner has been pushed all the way in, press inwards
and downwards as indicated by the arrow shown here, until it clicks into
place. The front panel will not register the new printhead cleaner until the
right-hand door is closed.
3 When you have inserted the printhead cleaner(s) into the printer, close the
door.
NOTE: The printer needs all the ink cartridges, printheads, and printhead
cleaners to be installed before it can continue.
4 If no printing material is loaded, the front panel will instruct you to load
some.
After replacing a printhead and printhead cleaner
Whenever a printhead is replaced, the printer will normally perform a
printhead alignment. If you wish, you can turn off this automatic alignment
