C-series Fibre Channel switch parameters
Execute the commands in
for each VSAN that will use the FCIP link. Enter
configuration commands based on the storage system, one per line in the order listed below.
Table 14 Settings for C-series switches
HP storage system
Command
P6000/EVA
P9000/XP
C-Switch# config
C-Switch(config)# in-order-guarantee VSAN #
(where # stands for all
VSANs that use the FCIP link)
P10000/3PAR
C-Switch(config)# vsan database
C-Switch(config-vsan-db)# vsan # loadbalancing [src-dst-id]
or [src-dst-ox-id](See NOTE below.)(where # stands for all VSANs that use
the FCIP link)
C-Switch(config-vsan-db)# exit
C-Switch(config)# exit
C-Switch# copy run start
NOTE:
For P6000 Continuous Access:
•
For B-series, specify 1 for port-based routing (all XCS versions) or 3 for exchange-based routing
(XCS 09534000 or later).
•
For C-series, specify src-dst-id for port-based routing (all XCS versions) or src-dst-ox-id for
exchange-based routing (XCS 09534000 or later).
•
For port-based routing, set the P6000 Continuous Access data replication protocol to HP FC
Data Replication Protocol.
•
For exchange-based routing, use HP SCSI FC Compliant Data Replication Protocol.
H-series Fibre Channel switch parameters
Use the default H-series switch settings. The H-series switches employ exchange-based routing;
therefore P6000 Continuous Access support with H-series switches requires XCS 09534000 or
later and HP SCSI FC Compliant Data Replication Protocol.
Configuring the mpx110 for connecting remote SANs
Verify the SAN configuration requirements:
•
At least one FC port of each mpx110 should be connected to an FC SAN.
•
Use FC WWPN-based zoning.
