CAUTION:
Guard plates prevent access to the inside of the library when a load port magazine is
removed. These doors will move back out of the way when a magazine is reinserted. You
should not attempt to otherwise move these guards, nor gain access to the library through
the load ports.
Replacing a load port magazine
1. Align the magazine with the top and bottom track on the load port door, and slide the magazine
through the spring door and fully into the load port.
2. Close the load port door.
3. After all load port doors are closed, the library does an inventory of the load ports.
10443
Figure 56 Inserting a magazine into the load port
