Table 3 Ultrium compatibility
Tape drive 200 GB 1 400 GB 1 800 GB 1 WORM 800
GB 1
1600 GB 1 WORM
1600 GB 1
Ultrium 460
(LTO2)
Read/write Optimum
Not
supported
Not
supported
Not
supported
Not
supported
Ultrium 960
(LTO3)
Read only Read/write Optimum Optimum
Not
supported
Not
supported
Ultrium
1840 (LTO4)
Not
supported
Read/write Read/write Read/write Optimum Optimum
1 Values assume a 2:1 compression ratio
Tape cartridges and cleaning cartridges are specifically formatted for use with Ultrium drives. To order
Ultrium tape cartridges, see Appendix C .
Switch for the internal network
CAUTION:
Do not connect this switch to your local LAN. It is for internal library use only. Connecting this switch to
the LAN could cause library components to perform incorrectly or report failures.
The 24-port Ethernet switch provides a private management network to connect the Interface Manager
card to the LTO4 tape drives. You must install one switch in each library that contains LTO4 tape drives.
This switch is a store-and-forward device that offers low latency for high-speed networking.
The EML library uses a ProCurve Switch 1700-24. This switch has 22 auto-sensing 10/100Base-TX RJ-45
ports and two dual-personality ports (ports 23 and 24). Because the RJ-45 ports support automatic
MDI/MDI-X operation, you can use straight-through cables for all network connections.
Dual-personality ports use either the 10/100/1000Base-T RJ-45 connector, or a supported ProCurve
mini-GBIC for fiber-optic connections. By default, the RJ-45 connectors are enabled.
The features of the Procurve Switch 1700-24 include the following.
11595
1
2
Figure 15 Ports on the switch for the internal network
1 10/100Base-TX RJ-45 ports
2 Dual-personality ports
