Figure 53 Removing a power supply from a card cage expansion module
Replacing a power supply in the card cage expansion module
1. Orient the power supply as shown in Figure 53 on page 92. Align the power supply with the guides
in the card cage and slide the power supply into the library.
2. Push the ejector handle to the right.
3. Tighten the two captive screws. Use a #2 Phillips screwdriver.
LTO2 or LTO3 tape drive
Part number 375817-001 or 409859-001 (Ultrium 460 or LTO2)
nl 381676-001 or 409860-001 (Ultrium 960 or LTO3)
Location In the base module or tape drive expansion module
Characteristics
• Hot-swappable
• 1/2-inch cartridge tape drive
Function
Writes data to and reads data from Linear Tape-Open (LTO)
cartridges
Illustration
gl01014
Required tools
• Flat-blade screwdriver
Removing an LTO2 or LTO3 tape drive
1. Identify the tape drive to be replaced. The FAULT LED light might be lit (see
“ HP StorageWorks Ultrium tape drives ” on page 58).
92 Removing and replacing parts
