Table 5 Status screen functions
Function Description
Identity Screen
Contains basic configuration information. The library name and IP
address is obtained from Command View TL. Other information comes
from the robot firmware.
The number of interface controllers and tape drives installed in the
library are listed, as well as the total number of available storage slots.
For example, load port slots configured as storage slots are counted in
the total of available slots, while load ports used to move tape cartridges
in and out of the library are not counted in the total.
This screen also shows the library model, library serial number, and
library firmware version.
Health Summary
Displays a status icon and health information for the library, robot,
power supplies, load ports, tape drives, interface controllers, and
Interface Manager card.
Component Status
Identifies the status of the overall library and individual components:
• Library and Robotics—Displays library and robotics characteristics,
and tape drive odometer. The odometer counts the number of loads
for each tape drive. The load count is reset when a tape drive is
replaced.
• Individual Drive Status—Displays detailed tape drive information for
each tape drive on individual screens. Select the Page Up and Page
Down tabs to move between available tape drives.
• All Drive Summary—Displays an overall status of all installed tape
drives and whether they contain tape cartridges.
• Interface Controller Status—Displays the status for individual interface
controllers, showing the number of host ports, device ports, and
firmware revision.
• Interface Manager Status—Displays health and configuration
characteristics of the Interface Manager card.
Event Log Type Selection
Allows you to filter informational, warning, and critical events. The
five most recent events of any category are displayed with the oldest
displayed first and the most recent displayed last. Filtering events does
not remove them from the log.
View Library Inventory Identifies the status of each tape drive and slot location.
Configuration screen
The Configuration screen provides administrator access to screens that allow you to change the library
configuration or adjust the contrast of the OCP screen.
