Page 187: Volumes

Hitachi TrueCopy for z/OS user guide 187
NOTE:
For more information on HXRC device blocking and load balancing control, see ”
Pinned track recovery for TrueCopy volumes
If a pinned track occurs on a TC390 M-VOL or R-VOL, the MCU will suspend the pair (SIM reference code
= D41x, D42x, DB1x, DB2x). Use the following procedure to ensure full data integrity of the volume pair
while recovering the pinned track:
1.
Connect to the MCU of the TCz pair that contains the volume with the pinned track, and select the
correct CU image.
2.
Delete the TCz pair that contains the volume with the pinned track.
NOTE:
If you delete the TCz pair containing the volume with the pinned track, delete only the pair
containing the volume with the pinned track. To delete only the TCz Asynchronous volume pair
containing the volume with the pinned track, select Volume for Asynchronous Parameters and
Delete Range.
3.
If the volume is offline (for example, R-VOL has pinned track)), vary the volume online.
4.
Perform your usual procedure for recovering data from a pinned track, referring to the pinned track
recovery procedures for your operating system. Contact your HP account support representative to
inform them of the pinned track.
5.
If the volume was previously offline (for example, R-VOL), make sure to vary the volume offline again.
6.
Restart the volume pair using the Add Pair window, making sure to use the Entire initial copy option.
NOTE:
Be sure to specify the volume pair for which the pinned track recovery operation was performed.
SIM reporting
The XP12000/XP10000 reports a service information message (SIM) to the host when it is necessary to
notify the user of a possible service requirement for the disk array. The SIMs are classified according to
severity for reporting and logging purposes: service, moderate, serious, or acute. The SVP reports all SIMs
related to TC390 operations and all SIMs are stored on the SVP for use by HP personnel. The SIMs
reported to the zSeries and S/390 host are logged in the SYS1.LOGREC dataset of the host operating
system. Each time a SIM is generated, the amber Message LED on the XP12000/XP10000 control window
(under the Ready and Alarm LEDs) turns on as an additional alert for the user. The XP12000/XP10000
Primary disk array
interface
Parallel or ESCON
ESCON only
ESCON only
Secondary disk array
interface
Parallel or ESCON
Parallel or ESCON
Parallel or ESCON
Channel extender
support
Yes
Contact your HP account
support representative for the
latest information.
Contact your HP account
support representative for the
latest information.
Maximum sidefile size 50%
50% available cache
50% available cache
Sidefile puncture %
60%
60%. Retries issued at 40%
utilization, host interface
blocked at 50% utilization.
60%. Retries issued at 40%
utilization, host interface
blocked at 50% utilization.
Table 47
GDPS-TC390-HXRC matrix (continued)
zSeries and S/390
Feature
IBM 3990-6E
XP12000/XP10000
XP48/XP512
