Description
Item
•
External: External volume
•
Snapshot: FS volume
The LDEV’s CLPR number.
CLPR
BC only.
Number of Secondary Volumes
The number of S-VOLs that the selected P-VOL has been assigned so far.
Click to open the LDEV Properties window, which contains additional information
for the selected LDEV.
Detail button
Selected Pairs table
The following table shows the items in this table of the Select Secondary Volumes window of the
Create Pairs wizard.
Description
Item
The P-VOL information.
Primary Volume
Values:
•
LDEV ID: The P-VOL’s LDEV identifier.
•
LDEV Name: The P-VOL’s LDEV name.
•
Port ID: The port name of the P-VOL LDEV’s LUN path.
•
Host Group Name: Host group name of the P-VOL LDEV’s LUN path.
•
LUN ID: The LUN identifier of the P-VOL LDEV's LUN path.
•
Emulation Type: The P-VOL’s emulation type.
•
Capacity: The P-VOL’s volume capacity.
For BC Z, Port ID, Host Group Name, and LUN ID do not display.
For FS, Emulation Type does not display.
The S-VOL.
Secondary Volume
Values:
•
LDEV ID: The S-VOL’s LDEV identifier.
This item is blank if no LDEV is assigned.
•
LDEV Name: The S-VOL’s LDEV name.
A hyphen (-) displays if no LDEV is assigned.
•
Port ID: Port name of the S-VOL LDEV’s LUN path.
•
Host Group Name: Host group name of the S-VOL LDEV’s LUN path.
•
LUN ID: LUN identifier of the S-VOL LDEV's LUN path.
•
Emulation Type: The S-VOL’s emulation type.
•
Capacity: The S-VOL’s volume capacity.
For BC Z, Port ID, Host Group Name, and LUN ID do not display.
For FS, Emulation Type does not display.
The copy type.
Copy Type
Values:
•
BC-L1: BC/SS L1
•
BC-L2: BC/SS L2
•
BC Z: BC Z
•
FS: FS
