Description Item
The S-VOL information. Secondary Volume
Values:
• LDEV ID: The S-VOL’s LDEV identifier.
•
LDEV name: The S-VOL’s LDEV name.
• Provisioning type: The S-VOL’s provisioning type, which can be one of the following:
◦
Basic: Internal volume
◦
THP: THP V-VOL
◦
External: External volume
◦
Snapshot: FS volume
• Emulation type: The S-VOL’s emulation type.
•
Capacity: The S-VOL’s volume capacity.
• CLPR: The S-VOL’s CLPR number.
•
Mode: Indicates whether the XP7 storage system has written to the S-VOL. For BC,
this item also indicates whether the XP7 storage system can read the S-VOL.
◦
For BC:
- W is shown when the XP7 storage system has written data to the S-VOL. W is
also shown when the XP7 storage system has written data to the S-VOL and the
S-VOL cannot be read when its pair status is “PSUS(SP)/PSUS” or “PSUS”.
- N is shown when the S-VOL cannot be read because you specified “-m noread”
using RAID Manager.
- A hyphen (-) indicates that the XP7 storage system has not written to the S-VOL.
◦
For FS:
- W is shown if the XP7 storage system has written data to the S-VOL when its
pair status is “PSUS(SP)/PSUS” or “PSUS”.
- A hyphen (-) indicates that the XP7 storage system has not written to the S-VOL.
◦
For BC Z:
- W is shown when the XP7 storage system has written data to the S-VOL when
its pair status is “V-Split/SUSPVS” or “Split/SUSPOP”.
- Protect is shown when you have set the Protect attribute using BCM when the
S-VOL’s pair status is “Split/SUSPOP”, “SP-Pend/TRANS”, or “V-Split/SUSPVS”.
- A hyphen (-) indicates that the XP7 storage system has not written to the S-VOL.
Values (continued): Secondary Volume (continued)
• Virtual Storage Machine: The model type and serial number of the virtual storage
machine to which the S-VOL belongs.
•
Virtual LDEV ID: The identification number of the S-VOL’s virtual LDEV. If no virtual
LDEV ID is assigned, a blank displays.
• Virtual Device Name: The name of the S-VOL’s virtual device, in a combined format
of “virtual emulation type”, “number of virtual LUSE volumes”, and “virtual CVS
attribute”. Each of these three items displays only if it is specified. If none of them
are specified, a blank displays.
• Virtual SSID: The virtual SSID of the S-VOL. If no virtual SSID is specified, a blank
displays.
The identification number for the CG to which the pair is assigned. CTG ID
BC and BC Z only. Copy Pace
View Pair Properties window 119
