Available LDEVs table
This table is shown on the Select Primary Volumes window.
The following table lists the items in this table.
Description Item
The LDEV’s identifier. LDEV ID
The LDEV’s name. LDEV Name
BC and FS only. Port ID
The port name of the LDEV’s LUN path.
BC and FS only. Host Group Name
The host group name of the LDEV’s LUN path.
BC and FS only. LUN ID
The LUN identifier of the LDEV's LUN path.
The LDEV’s provisioning type. Provisioning Type
Values:
•
Basic: Internal volume
•
THP: THP V-VOL
• External: External volume
BC and BC Z only. Emulation Type
The LDEV’s emulation type.
The LDEV’s capacity. Capacity
The LDEV’s CLPR number. CLPR
The total number of S-VOLs assigned to the P-VOL. This value includes the volumes
for pairs that you are creating, volumes in existing pairs. For an L1 pair, this
value does not include the number of L2 S-VOLs. Number of Secondary Volumes
Click to move the selected LDEVs from the Available LDEVs table to the Selected
LDEVs table. Add button
Click to move the selected LDEVs from the Selected LDEVs table to the Available
LDEVs table. Remove button
Selected LDEVs table
This table is shown on the Select Primary Volumes window.
The following table shows the items in this table.
Description Item
The selected P-VOL’s LDEV identifier. LDEV ID
The selected P-VOL’s LDEV name. LDEV Name
BC and FS only. Port ID
The port name of the LDEV’s LUN path.
BC and FS only. Host Group Name
The host group name of the LDEV’s LUN path.
BC and FS only. LUN ID
The LUN identifier of the LDEV's LUN path.
