5 Parameters
BU 0500 GB-1013 133
Pos : 337 /Anleit ungen/5. / 6. Parametrier ung [BU 0500 / BU 0200]/ Par ameter/ P700-P799/ Paramet er P710 – Spannung Analogausgang [ SK 500.. .535E] @ 0\ mod_1328172381803_388. doc x @ 12571 @ @ 1
P710
Analog output voltage
(Analog output voltage)
0.0 ... 10.0 V Displays the value which is output from analog output 1.
Pos : 339 /Anleit ungen/5. / 6. Parametrier ung [BU 0500 / BU 0200]/ Par ameter/ P700-P799/ Paramet er P711 – Zus tand Digital e Ausg änge @ 0\mod_1328172550774_388. doc x @ 12617 @ @ 1
P711
State of relays
(State of digital outputs)
000000000 ...
111111111 (binary)
(Display with
*SK-TU3-PAR)
or
0000 ... 01FF (hex)
(Display with
*SK-TU3-CTR
*SK-CSX-0)
Displays the actual status of the signal relays.
Bit 0 = Relay 1
Bit 1 = Relay 2
Bit 2 = Digital output 1 (SK 520E and above)
Bit 3 = Digital output 2 (SK 520E and above)
Bit 4 = Analog output 1 (digital function)
Bit 5 = Digital output 3 (SK 540E and above)
Bit 6 = Digital output 1/1 IOE (SK 540E and above)
Bit 7 = Digital output 2/1 IOE (SK 540E and above)
Bit 8 = Digital output 1/2 IOE (SK 540E and above)
Bit 9 = Digital output 2/2 IOE (SK 540E and above)
Pos : 340 /Anleit ungen/5. / 6. Parametrier ung [BU 0500 / BU 0200]/ Par ameter/ P700-P799/ Paramet er P712 – Spannung Analogei ngang 2 [SK 500... 535E] @ 0\ mod_1328172634224_388. doc x @ 12640 @ @ 1
P712
Voltage analog input 2
(Voltage analog input 2)
-10.00 ... 10.00 V Displays the measured analog input value 2.
Pos : 341 /Anleit ungen/5. / 6. Parametrier ung [BU 0500 / BU 0200]/ Par ameter/ P700-P799/ Paramet er P714 – Betriebs dauer @ 0\ mod_1328172684685_388. doc x @ 12663 @ @ 1
P714
Operating time
(Operating time)
0.10 ... ___ h This parameter shows the time for which the FI was connected to the mains and was ready for
operation.
Pos : 342 /Anleit ungen/5. / 6. Parametrier ung [BU 0500 / BU 0200]/ Par ameter/ P700-P799/ Paramet er P715 – Freigabedauer @ 0\ mod_1328172731474_388.doc x @ 12686 @ @ 1
P715
Running time
(Enablement time)
0.00 ... ___ h This parameter shows the time for which the FI was enabled and supplied current to the output.
Pos : 343 /Anleit ungen/5. / 6. Parametrier ung [BU 0500 / BU 0200]/ Par ameter/ P700-P799/ Paramet er P716 – Akt uelle Fr equenz @ 0\ mod_1328172775215_388.doc x @ 12709 @ @ 1
P716
Current frequency
(Actual frequency)
-400.0 ... 400.0 Hz Displays the actual output frequency.
Pos : 344 /Anleit ungen/5. / 6. Parametrier ung [BU 0500 / BU 0200]/ Par ameter/ P700-P799/ Paramet er P717 – Akt uelle Dr ehzahl @ 0\ mod_1328172889966_388.doc x @ 12732 @ @ 1
P717
Current speed
(Actual rotation speed)
-9999 ... 9999 rpm Displays the actual motor speed calculated by the FI.
