Waveform screen – KYORITSU 6310 Instruction Manual User Manual
Page 185
KEW6310 9.1.1 WAVE Range – Display Screen
KEW6310
9.2
Waveform screen
Voltage and current waveforms can be displayed together or displayed channel by channel.
Number of Ch for displayed waveform depends on the selected wiring configuration.
Symbols displayed on the LCD
changing a magnification of voltage
changing a magnification of current
switching to Vector screen
switching to Waveform screen
Measured value at each Ch
Waveform
CH
Power source/ Time
Function Keys
Magnification
