KROHNE OPTISONIC 6300 EN - Manual (Page 94)

6
OPERATION
94
OPTISONIC 6300
www.krohne.com 07/2009 - 4000263902 - HB OPTISONIC 6300 R03 en
F over range A
(or B, D)
pulse on frequency output A (or B,
D) is limited by parameter setting
extend upper or lower limit for
frequency output in menu C5.3.7
F active settings error during CRC check (Cyclic
Redundancy Check) of the active
settings
load settings; factory setting, back
up 1 or back up 2
F factory settings error during CRC check of factory
settings
F back up 1 (or 2)
settings
error during CRC check of back up
1 (or 2) settings
F signal lost path
1
signal lost at path 1 check signal cable / check for pipe
obstructions
F signal lost path
2
signal lost at path 2 check signal cable / check for pipe
obstructions
F pipe/sens1
param.
unrealistic parameter settings for
pipe in combination with path 1
check parameters in menu X6
F pipe/sens2
param.
unrealistic parameter settings for
pipe in combination with path 2
check parameters in menu X6
S unreliable 1 unreliable measurement at pipe 1 check process conditions for gas
bubbles, solids
S unreliable 2 unreliable measurement at pipe 2 check process conditions for gas
bubbles, solids
S zero converter invalid value at power up power off - wait 5 seconds - power
on device
S overflow
counter 1 (or 2,
3)
counter is overflowing and will
start again at zero
no action needed
S backplane
invalid
error during CRC check of
backplane
restore data records on backplane
I counter 1 (or 2,
3) stopped
counter has stopped reset counter in menu C8.9.1 (or
C8.9.2, C8.9.3)
I control input A
(or B) active
information only no action needed
I over range
display 1 (or 2)
1 st row on 1 st (or 2 nd )
measurement page is limited by
parameter setting
extend upper or lower limit for
limitation in menu C8.3.4
I backplane
sensor
incompatible data sensor on
backplane
I backplane
settings
incompatible data on backplane
I backplane
difference
different data on backplane and
display
I optical
interface
optical interface is operational,
local display can not be used
I softw sync
error
incompatible DSP and
microprocessor software
Error Error Error Error
code
code code code
Group Group Group Group
message
message message message
Error Error Error Error
message
message message message
Description Description Description Description Error handling Error handling Error handling Error handling
