6
OPERATION
80
OPTISONIC 6300
www.krohne.com
07/2009 - 4000263902 - HB OPTISONIC 6300 R03 en
C4
transducer sets
>
C4.1, C4.2,…
↑ ↓
^
C4.1
Ta serial no.
>
fill in using ↑ ↓ >
^
C4.2
Ta calibration no.
>
fill in using ↑ ↓ >
^
C4.3
Tb serial no.
>
fill in using ↑ ↓ >
^
C4.4
Tb calibration no.
>
fill in using ↑ ↓ >
^
C4.5
Tc serial no.
>
fill in using ↑ ↓ >
^
C4.6
Tc calibration no.
>
fill in using ↑ ↓ >
^
C5
I/O
>
C5.1, C5.2,…
↑ ↓
C5.1
hardware
>
C5.1.1, C5.1.2,…
↑ ↓
^
C5.1.1
terminals A
>
select current
output/off using ↑
↓
^
C5.1.2
terminals B
>
select from list
using ↑ ↓
^
C5.1.3
terminals C
>
select from list
using ↑ ↓
^
C5.1.4
terminals D
>
select from list
using ↑ ↓
^
C5.2
current out A
>
C5.2.1, C5.2.2,…
↑ ↓
^
C5.2.1
range 0-100%
>
fill in using ↑ ↓ >
^
C5.2.2
extended range
>
fill in using ↑ ↓ >
^
C5.2.3
error current
>
fill in using ↑ ↓ >
^
C5.2.4
error condition
>
select from list
using ↑ ↓
^
C5.2.5
measurement
>
select from list
using ↑ ↓
^
C5.2.6
range
>
fill in using ↑ ↓ >
^
C5.2.7
polarity
>
select from list
using ↑ ↓
^
C5.2.8
limitation
>
fill in using ↑ ↓ >
^
C5.2.9
low flow cutoff
>
fill in using ↑ ↓ >
^
C5.2.10
time constant
>
fill in using ↑ ↓ >
^
C5.2.11
special function
>
select from list
using ↑ ↓
^
C5.2.12
threshold
>
fill in using ↑ ↓ >
^
C5.2.13
information
>
read
^
C5.2.14
simulation
>
select set
on/off/cancel
^
C5.2.15
4 mA trimming
>
fill in using ↑ ↓ >
^
C5.2.16
20 mA trimming
>
fill in using ↑ ↓ >
^
C5.3
frequency out X
>
C5.3.1, C5.3.2,…
↑ ↓
^
C5.3.1
pulse shape
>
select from list
using ↑ ↓
^
C5.3.2
pulse width
>
fill in using ↑ ↓ >
^
C5.3.3
100 % pulse rate
>
fill in using ↑ ↓ >
^
C5.3.4
measurement
>
select from list
using ↑ ↓
^
C5.3.5
range
>
fill in using ↑ ↓ >
^
