Device description, 2 device description – KROHNE OPTISONIC 6300 EN User Manual
Page 12
2
DEVICE DESCRIPTION
12
OPTISONIC 6300
www.krohne.com
07/2009 - 4000263902 - HB OPTISONIC 6300 R03 en
2.2 Device description
The ultrasonic clamp-on flowmeter can be fitted on the outside of piping to measure the flow
rate of liquids.
The device is a combination of one up to two clamp-on sensor(s) and one ultrasonic flow
converter.
Additionally for large version:
1 2
nd
sensor plus cover
2 90 degree screw driver
3 4 fixing units
4 Positioning tool
5 2 metal straps
6 Signal cable plus connector cap
7 Cable box plus signal cable
INFORMATION!
No special tools, no training required!
Figure 2-2: System configuration possibilities
.book Page 12 Tuesday, August 18, 2009 4:51 PM
