5
START-UP
66
OPTISONIC 6300
www.krohne.com
07/2009 - 4000263902 - HB OPTISONIC 6300 R03 en
Mount the positioning tool to the UP rail as shown.
1 Mark the cables at a distance of 1.63 x outer diameter.
2 Outer diameter of pipeline
INFORMATION!
For large diameters you can use the weight of the metal plates to throw the cable around the
pipe. First release one of the cables in that case!
