OPERATION
6
91
OPTISONIC 6300
www.krohne.com 07/2009 - 4000263902 - HB OPTISONIC 6300 R03 en
C5.6.7 simulation simulation of limit switch on, off, cancel
C5.7 C5.7 C5.7 C5.7 control input X control input X control input X control input X
C5.7.1 mode define function of control input off, hold all outputs, hold output X, all outputs to
zero, output X to zero, reset all counters, reset
counter X, stop all counters, stop counter X,
zero outp.+ stop cnt, range change X, error
reset
C5.7.2 invert signal off: activate a current
on: activate no current
C5.7.3 information serial number of circuit board,
software version, calibration date
of circuit board
C5.7.4 simulation simulation of control input on, off, cancel
C6 C6 C6 C6 I/O Counter I/O Counter I/O Counter I/O Counter
C6.1 C6.1 C6.1 C6.1…6.2 6.2 6.2 6.2 Counter 1 and 2 Counter 1 and 2 Counter 1 and 2 Counter 1 and 2 only if HART device
C.x.1 function of counter define counter off, +counter, -counter, sum counters
C.x.2 measurement select the measurement for the
counter
(depends on pipe configuration: 1 or 2 pipes)
volume flow, mass flow, volume flow 1 or 2
C.x.3 low flow cutoff set low values to zero (depends on parameter settings)
C.x.4 time constant within set time, measurements
are averaged, displayed and sent
to current output
min-max: 000.1 - 100.0
C.x.5 preset value active when under status output
mode (C2.5.1) preset counter X is
selected
min-max: 0.00000 - 1.00 +15
C.x.6 reset counter yes/no
C.x.7 set counter select set value on, off, cancel
C.x.8 stop counter stop counter and hold actual
value
yes/no
C.x.9 start counter start after stop counter yes/no
C.x.10 information serial number of circuit board,
software version, calibration date
of circuit board
C7 C7 C7 C7 I/O HART I/O HART I/O HART I/O HART only if HART device; HART
dynamic values are linked to
analog outputs
free selectable only if analog output is NOT
active
C7.1 PV is Primary Variable; linked to HART
current output
C7.1.1 current output A show selected value
C7.1.2 frequency output X show selected value
C7.1.3 HART dynamic
variable
select the variable (depends on pipe configuration: 1 or 2 pipes)
volume flow, mass flow, VoS, flow speed, gain,
SNR, diagnosis value, volume flow 1 or 2, VoS 1
or 2, counter 1 or 2, operating hours
C7.2 SV is Secondary Variable; linked to
frequency output D
C7.3 TV is Third Variable
C7.4 4V is Fourth Variable
C8 C8 C8 C8 device device device device
C8.2.2 contrast min-max: -9 - +9
C8.2.3 default display 1.meas.page, 2.meas.page, graphic page,
status page, none
