6
OPERATION
92
OPTISONIC 6300
www.krohne.com 07/2009 - 4000263902 - HB OPTISONIC 6300 R03 en
C8.3 settings for first and second
measurement display
C8.3.1 function one, two, three line(s)
C8.3.2 measurement
1.line
(depends on pipe configuration: 1 or 2 pipes)
volume flow, mass flow, VoS, flow speed, gain,
SNR, diagnosis value, volume flow 1 or 2, VoS 1
or 2
C8.3.3 range set measurement range from 0
to 100 %
(depends on parameter settings)
C8.3.4 limitation set lower and upper limit min-max: -150 - +150 %
C8.3.5 low flow cutoff set low values to zero min-max: 00.0 - 20.0
C8.3.6 time constant within set time, measurements
are averaged, displayed and sent
to current output
min-max: 000.1 - 100.0
C8.3.7 format 1.line number of decimals automatic, No.x.xxxx (no - four decimals)
C8.3.8 measurement
2.line
bargraph, operating hours, counter 1, counter
2, diagnosis value, SNR, gain, flow speed, mass
flow, VoS, volume flow
C8.5.1 select range set Y-axis scaling manual, automatic
C8.5.2 range active if under select range
(C5.5.1) manual is selected
min-max: -100 - +100%
C8.5.3 time scale set X-axis scaling min-max: 001 - 100 min
C8.6.2 save settings factory settings, back up 1, back up 2, cancel
C8.6.3 load settings factory settings, back up 1, back up 2, cancel
C8.6.4 password quick
setup
0000 - 9999
C8.6.5 password setup 0000 - 9999
C8.7 units
C8.7.1 volume flow L/s, L/min,L/h, m3/s, m3/min, m3/h, m3/d,
ft3/s, ft3/min, ft3/h, gal/s, gal/min,gal/h, gal/d,
IG/s, IG/min, IG/h, IG/d, bbl/h, bbl/d, free unit
C8.7.2 mass flow kg/s, kg/min, kg/h, t/min, t/h, t/d, lb/s, lb/min,
lb/h, ST/min, ST/h, ST/d, LT/h, LT/d, gs, g/min,
g/h, free unit
C8.7.3 flow speed m/s, ft/s
C8.7.4 velocity m/s, ft/s
C8.7.5 volume m3, in3, ft3, yd3, mL, L, hL, gal, IG, bbl, free unit
C8.7.6 mass mg, g, kg, t, oz, lb, ST, LT, free unit
C8.7.7 density kg/L, kg/m3, lb/ft3, lb/gal, free unit
C8.7.8 viscosity cSt, m2/s, mm2/s
C8.8.1 HART factory setting: HART
communication on; generates F:
application error open circuit A
