BIN FUNCTIONS
71
5. To clear the test results, press CLR
followed by F3 (YES->) to confirm.
6. Press EXIT to exit the bin summary
results.
LCR-800 User Manual
72
R
S232 REMOTE
The LCR-821 (LCR-816/817/819 as options)
includes RS232C remote connectivity. With the
RS232 VIEWER software, the LCR meter can be
remotely controlled and all test results can be
saved to a PC.
LCR Setup
RS232 Settings ............................................................. 73
LCR Viewer
LCR VIEWER Display Overview ................................... 74
LCR Viewer Connection and File Settings .................. 75
LCR Viewer File Settings .............................................. 78
LCR Viewer Remote Measurement ............................. 80
View Data ..................................................................... 81
Terminal
Connection
Configure Terminal Connection .................................. 84
