B1-32
IM 01W01F01-01EN
▪ The status of bad/configuration error means that the adjustment and settings of the device
have not been performed correctly. Adjust and set the device again using PRM.
▪ The status of bad/device failure and bad/sensor failure means that the device has a failure.
Contact the device vendor.
▪ When the status is bad/non-specific or uncertain, either refer to the user's manual of the
device, or contact the device vendor.
l Time required for the value to displayed on the page of the Readings tab
Immediately after the download to YFGW710 or the field wireless device has been performed, or
immediately after the device has joined the field wireless network, it may take a maximum of 15
minutes until process data communication between the device and YFGW710 starts.
B1.2.8 Engineering of Control System
The field wireless network and a control system can be connected, and the control system is able
to access the process data of the field wireless device.
Refer to the engineering manual of each control system.
n Exporting a Modbus Register Map
When a Modbus Register map is assigned using Field Wireless Configurator, the map can be ex-
ported to a CSV file and used for system engineering. For details on the export procedure, refer
to Part C C2 “Field Wireless Configuratior” of this document.
An export file includes the following information.
▪ Format Rev: Fixed to 1
▪ Project Name: Project name
▪ IPv4: IP address of YFGW710
▪ Device Tag: Device tag
▪ TSAP ID: Area information in the field wireless device where the parameters set in the Mod-
bus Register map are located. Fixed to 0xF0B2
▪ Object Name: Name of the object (block) where the target parameter is located
▪ Object ID: ID of the object (block) where the target parameter is located. Refer to the user's
manual of the field wireless device that uses the ID of the target block.
▪ Parameter Name: Target parameter name
▪ Attribute ID: ID of the target parameter. Refer to the user's manual of the field wireless de-
vice that uses the ID of the target parameter.
▪ Attr ID: Fixed to 0
▪ Data Type: Number indicating the data type of the target parameter
Table B1-14 Data Type
Data Type No. Size Example
Unsigned32 0x07 4 Bytes DIAG_STATUS
Process control value and status of analog 0x41 5 Bytes PV
Process control value and status for binary 0x42 2 Bytes PV_B
▪ Start Input Register Number: Register number assigned to the target parameter. The range
is from 0 to 65535.
▪ Input Register Size: Size assigned to the target parameter (in word)
