<6. PARAMETER DESCRIPTION>
6-42
IM 01E30D01-01EN
(1) Display and output condition for system alarms
Alarm description
Alarm
Output
4-20mA
output
Totalization
Pulse
Display unit
Alarm
record
Normal
Closed
(ON)
Normal
Normal
Normal
Display Mode No
10 μP Fault
Microprocessor
(CPU) failure
Open
(Off)
Fixed at
3.2mA or less
otherwise
21.6mA or
more (*)
Indetermination Indetermination Indetermination Indetermination
11 EEPROM
Fault
EEPROM failure
Open
(Off)
Fixed at
3.2mA or less
otherwise
21.6mA or
more (*)
Stopped
Stopped
Alarm Mode
(display of
system Alarm
message)
Recorded
12 Sub uP Fault Substitute
mcroprocessor
(CPU) failure
13 EX Pwr Fault Extitation power
circuit failure
14 A/D(S) Fault
A/D converter failure
(Signal)
15 A/D(I) Fault
A/D converter failure
(Excitation current)
16 Analog Fault Analog circuit failure
17 Coil Open
Flowtube coil is
open-circuit
18 Coil Short
Flowtube coil is
short-circuit
19 Excite Error
Excitation circuit
failure
20 Pulse Error
Discrepancy of
pulse count
21 EEPROM
Dflt
EEPROM default
values
Note: • Alarm is output only when
[F10:DO Function] is set to “Alarm Output.”
• The operation when “Open (Off) Act” is set for
[F11:DO Active Mode] is shown in above table.
*: The output value is performed in accordance with the setting of the burnout switch. For information about this switch, see Section 10.3.1.
(2) Display and output condition for process alarms
Alarm description
Selection
(parameter
number)
Alarm
output
4-20 mA
output
Totalization
Pulse
output
Displayunit Alarm
record
30 Sig Overflow Input signal error
YES
(G26)
Open
(Off)
Fixed
Stopped
Stopped Alarm Mode
(Message)
Recorded
NO
(G26)
Closed
(On)
Continuous
(*)
Continuous
(*)
Continuous
(*)
Display
Mode
No
31 Empty Pipe
Flowtube is not filled
with fluid
YES
(G27)
Open
(Off)
Fixed
Stopped
Stopped Alarm Mode
(Message)
Recorded
NO
(G27)
Closed
(On)
Continuous
(*)
Continuous
(*)
Continuous
(*)
Display
Mode
No
32 H/L Alm
H/L Alarm
YES
(G28)
Open
(Off)
Normal
operation
Normal
operation
Normal
operation
Alarm Mode
(Message)
No
NO
(G28)
Closed
(On)
Display
Mode
33 Adhesion Alm Electrode adhesion
alarm
YES
(G29)
Open
(Off)
Fixed
Stopped
Stopped Alarm Mode
(Message)
Recorded
NO
(G29)
Closed
(On)
Continuous
(*)
Continuous
(*)
Continuous
(*)
Display
Mode
No
Note: • larm is output only when
F10: DO Function is set to “Alarm Output.”
• The operation when “Open (Off) Act” is set for
F11: DO Active Mode is shown in above table.
• 4-20mA output upon the occurrence of an alarm will be fixed at the value selected with
G25: 4-20mA Process Alarm.
*: Although outputs are continuous, output values are not guaranteed.
