<8. OPERATION VIA HART CONFIGURATION TOOL (HART 5)>
8-3
IM 01E30D01-01EN
8.4 Basic Setup
n Confirmation and Change of Tag and
Device Information
The tag number and device information can be
checked as follows:
• The location for the tag number and device
information
(DD)
Tag Device Setup → Detailed Setup
→ Basic setup → Tag
Descriptor Device Setup → Detailed Setup
→ Device information → Field device
information → Descriptor
Message Device Setup → Detailed Setup
→ Device information → Field device
information → Message
Date Device Setup → Detailed Setup
→ Device information → Field device
information → Date
(DTM)
Tag Easy Setup → Tag
or Configuration → HART → Tag
Descriptor Configuration → Device infomation 1
→ Descriptor
Message Configuration → Device infomation 1
→ Message
Date Configuration → Device infomation 1
→ Date
When changing the tag number or device
information, enter the information directly within the
following limitations.
Item Number and characters
Tag 8
Descriptor 16
Message 32
Date 2/2/2 (mm/dd/yy)
• mm : month
• dd : day
• yy : year
8.5 Parameters Configuration
The parameter structure of the HART configuration
tool is hierarchical.
Refer to 8.9 or 8.10, Menu Tree Example for the
corresponding parameters. The menu tree shows
a cross-reference of the parameters for HART and
BRAIN.
See “Chapter 6 Parameter Description” for the
functions of parameters.
Note that some display parameters of AXR are
different from those of HART configuration tools.
8.6 Data Renewing
There are two methods to load the AXR data
from/to HART Configuration Tool --- periodic data
renewing and discretionary data renewing. Refer to
the 8.9 or 8.10 menu tree for each corresponding
parameter.
(1) Periodic Data Renewing
The data is updated 0.5 to 2 second cycles. The
parameter of this type is marked as “D” in “Data
Renewing” of the 8.9 or 8.10 menu tree.
(2) Discretionary Data Renewing
The data can be loaded from/to the AXR when
the data save is finished to the Configuration
Tool. The parameter of this type is marked as
“S” in “Data Renewing” of the 8.9 or 8.10 menu
tree.
NOTE
The AXR is not able to set parameters via its
display unit during a communication of the HART
Configuration Tool.
