12-23
IM 01E30D01-01EN
<12. OUTLINE>
● Flameproof Packing Adapter for TIIS Flameproof Type (Optional code G11 or G32)
T1
T2
L
18
(0.71)
G
F
Adapter body (M. Screw)
O-Ring
Packing case
Hexagon socket set screw
Packing (*)
Hexagon socket set screw
O-Ring
O-Ring
Washer
Union nut
Packing gland
Clamp ring
Clamp nut
O-Ring
B. coupling
Cable (user’s scope)
*Packing
(Choose from the table below
depend on cable outside diameter)
D
C
16.5 (0.65)
Unit: mm (approx. inch)
Dimension
Cable outer diameter
T1
G 1/2 G 1/2
35
(1.38)
39
(1.54)
ø20.0
(0.79)
0.26
(0.57)
T2 C F G D
94.5
(3.72)
L
Packing diameter
Identification
mark
Weight
Kg (lb)
ø8.0 to ø10.0
(0.31 to 0.39)
ø10.0 to ø12.0
(0.39 to 0.47)
ш10.0
(0.39)
ш12.0
(0.47)
16 8-10
16 10-12
F1222.ai
● Unless otherwise specified, difference in the dimensions are refer to the following table.
General tolerance in the dimensional outline drawing.
Unit : mm (approx.inch)
Category of basic dimension
Tolerance
Category of basic dimension
Tolerance
Above Equal or below Above Equal or below
3 (0.12) ±0.7 (±0.03) 500 (19.69) 630 (24.80) ±5.5 (62.17)
3 (0.12) 6 (0.24) ±0.9 (±0.04) 630 (24.80) 800 (31.50) ±6.25 (60.25)
6 (0.24) 10 (0.39) ±1.1 (±0.04) 800 (31.50) 1000 (39.37) ±7.0 (60.28)
10 (0.39) 18 (0.71) ±1.35 (±0.05) 1000 (39.37) 1250 (49.21) ±8.25 (60.32)
18 (0.71) 30 (1.18) ±1.65 (±0.06) 1250 (49.21) 1600 (62.99) ±9.75 (60.38)
30 (1.18) 50 (1.97) ±1.95 (±0.08) 1600 (62.99) 2000 (78.74) ±11.5 (60.45)
50 (1.97) 80 (3.15) ±2.3 (±0.09) 2000 (78.74) 2500 (98.43) ±14.0 (60.55)
80 (3.15) 120 (4.72) ±2.7 (±0.11) 2500 (98.43) 3150 (124.02) ±16.5 (60.65)
120 (4.72) 180 (7.09) ±3.15 (±0.12)
180 (7.09) 250 (9.84) ±3.6 (±0.14)
250 (9.84) 315 (12.40) ±4.05 (±0.16)
315 (12.40) 400 (15.75) ±4.45 (±0.18)
400 (15.75) 500 (19.69) ±4.85 (±0.19)
Remarks: The numeric is based on criteria of tolerance class IT18 in JIS B 0401.
