12-12
IM 01E30D01-01EN
<12. OUTLINE>
*1: For explosion proof types, specify types of explosion proof certification using the optional codes.
For the TIIS flameproof type, select optional code G11. Available only for JIS G1/2 female electrical connections.
Available only for wiring of using a flameproof packing adapter approved by Yokogawa.
The flameproof metal conduit wiring for TIIS flameproof type is not permitted.
*2: Users must consider the characteristics of selected wetted parts material and influence of process fluids.
The use of inappropriate materials can result in the leakage of corrosive process fluids and cause injury to personnel and/or damage
to plant facilities. It is also possible that the instrument itself can be damaged and that fragments from the instrument can contami-
nate the user’s process fluids. Be very careful with highly corrosive process fluids such as hydrochloric acid, sulfuric acid, hydrogen
sulfide, sodium hypochlorite, and high-temperature steam (150°C [302°F] or above). Contact Yokogawa for detailed information of
the wetted parts material.
*3: Available only for metal piping.
*4: Mating dimensions are based on standards as follow:
ANSI:ASME B 16.5, DIN: DIN 2501, JIS:JIS B 2220 and JIS G 3443-2
*5: Allowable fluid pressure should also be limited according to fluid temperature and pressure.
*6: Even when DIN PN10, 16, or 40 is required for a model of size 25 to 50 mm (1.0 to 2.0 in.), select PN40 (Process connection codes:
BD4) because there is no difference in the dimensions of the mating faces.
Even when DIN PN10 or 16 is required for a model of size 65 to 150 mm (2.5 to 6.0 in.), select PN16 (Process connection codes: BD2)
because there is no difference in the dimensions of the mating faces.
*7: The dimensions of lay length code 1 are the same as those of the PFA lining standard lay length (lay length code 1) in the AXF series.
For details, refer to “EXTERNAL DIMENSIONS”.
*8: For an explosion proof type except for TIIS, select “ANSI 1/2 NPT female” or “ISO M20 × 1.5 female”.
For the TIIS flameproof type, select “JIS G1/2 female” and optional code G11.
*9: Select from among the figures at the right.
1 2 N
F1207.ai
*10: In the case of the TIIS flameproof type, select “with indicator” (code 1 or 2).
*11: Output signal code “-E”: HART 5.(Output signal code “-J” is recommended for HART communication.)
*12: Output signal code “-J”: HART 5 or HART 7 selectable. Specify HART 5 or HART 7 when ordering.
