Section 4 User Interface Guide Total Access 600 Series System Manual
66 © 2004 ADTRAN, Inc. 61200624L1-1B
To support these transfers, ADTRAN delivers a TFTP program with the unit called TFTP Server. You can
configure any PC running Microsoft Windows with this software, and store a configuration file.
Only one configuration transfer session (upload or download) can be active at a time. XMODEM and TFTP
are supported.
S
YSTEM
U
TILITY
> C
ONFIG
T
RANSFER
> T
RANSFER
M
ETHOD
The two methods for transferring a file are XMODEM and TFTP . (See the DLP section of this manual for
more information.) TFTP requires a TFTP server running on the network. The unit starts a TFTP client
function which gets the configuration file from the TFTP server or saves the existing configuration to the
TFTP server. Selecting
XMODEM will load the configuration file or save the file through the CRAFT port
using any PC terminal emulator with XMODEM capability. The factory default is TFTP .
S
YSTEM
U
TILITY
> C
ONFIG
T
RANSFER
> TFTP S
ERVER
IP A
DDRESS
Specifies the IP address of the TFTP server. Get this number from your system administrator. If using the
ADTRAN Utilities TFTP server, this number appears in the TFTP server status window. The factory
default value is
0.0.0.0 .
S YSTEM U TILITY > C ONFIG T RANSFER > TFTP S ERVER F ILENAME
Defines the name of the configuration file that you transfer to or retrieve from the TFTP server. The default
name is ta_iad.cfg, but you can edit this name.
S YSTEM U TILITY > C ONFIG T RANSFER > C URRENT T RANSFER S TATUS
Indicates the current status of the update.
S YSTEM U TILITY > C ONFIG T RANSFER > P REVIOUS T RANSFER S TATUS
Indicates the status of the previous update.
S
YSTEM
U
TILITY
> C
ONFIG
T
RANSFER
> L
OAD
A
ND
U
SE
C
ONFIG
Retrieves the configuration file specified in the TFTP S ERVER F ILENAME
field from the server. To start this
command, enter Y to begin or enter N to cancel.
S
YSTEM
U
TILITY
> C
ONFIG
T
RANSFER
> S
AVE
C
ONFIG
R
EMOTELY
Saves the configuration file specified in TFTP S ERVER F ILENAME
to the server identified in TFTP S ERVER
IP A DDRESS
. To start this command, enter Y to begin or enter N to cancel.
Before using S TART T RANSFER
, the unit should have a valid IP address, subnet mask, and
default gateway (if required). See DLP-3, Setting IP Parameters, for more information.
Before using this command, you must have identified a valid TFTP server in TFTP S ERVER
IP A DDRESS
.
