ADTRAN 600R User Manual
Page 134
Section 4 User Interface Guide
Total Access 600 Series System Manual
132
© 2004 ADTRAN, Inc.
61200624L1-1B
R
OUTER
> S
TATUS
View the
IP R
OUTES
,
IP S
TATS
,
ARP C
ACHE
,
DHCP S
ERVER
, and
DHCP C
LIENT
statistics from this menu.
R
OUTER
> S
TATUS
> IP R
OUTES
This lists the contents of the unit’s IP route table.
R
OUTER
> S
TATUS
> IP R
OUTES
> IP A
DDRESS
Network or host destination address.
R
OUTER
> S
TATUS
> IP R
OUTES
> N
ETMASK
Network mask applied to the destination address.
R
OUTER
> S
TATUS
> IP R
OUTES
> G
ATEWAY
Host or router to receive this packet.
R
OUTER
> S
TATUS
> IP R
OUTES
> P
ORT
Port gateway is located on:
R
OUTER
> S
TATUS
> IP R
OUTES
> U
SE
Number of times the unit has referenced the route.
UDP P
ORT
T
YPE
The choices are
S
TANDARD
(def) and
S
PECIFIED
. The following standard UDP protocols are relayed
when set: DHCP, TFTP, DNS, NTP (Network Time Protocol, port 123), NBNS (NetBios Name
Server, port 137), NBDG (NetBIOS Datagram, port 138), and BootP. When
S
PECIFIED
is set, the
UDP port (1 to 65535) can be specified in the UDP Port columns (up to three per server).
UDP P
ORT
1, 2, 3
Used for specifying UDP ports to be relayed. These fields only apply when
UDP P
ORT
T
YPE
is set to
S
PECIFIED
. Default is 0.
LOCAL
Sent directly to the unit’s router
ETH
0
The unit’s Ethernet port
WAN
0
The unit’s first PPP bundle
FR
0 . . .
FR
9
The unit is connected up to 10 DLCIs
