Section 4 User Interface Guide

Total Access 600 Series System Manual

106

© 2004 ADTRAN, Inc.

61200624L1-1B

C

ONNECTION

(V35) > S

ETUP

> S

ETUP

Use these menus to configure the Protocol mapping, DE map, and FECN map for the V.35 PVC
connections.

C

ONNECTION

(V35) > S

ETUP

> S

ETUP

> P

ROTOCOL

M

APPING

Network providers have the ability to provision each PVC pair with an encapsulation mode
to ensure interoperability between terminal equipment. The choices are

T

RANSPARENT

or

T

RANSLATION

(def).

T

RANSLATION

mode is most common and carries multiple upper layer

protocols over Frame Relay and ATM PVCs.

C

ONNECTION

(V35) > S

ETUP

> S

ETUP

> DE M

AP

Maps Frame Relay Discard Eligible (DE) bit to the ATM Cell Loss Priority (CLP) bit. The
choices are

DE = 0

,

DE = 1

, and

C

ONVERT

(map DE TO CLP). The factory default setting is

DE = 0

.

C

ONNECTION

(V35) > S

ETUP

> S

ETUP

> FECN M

AP

Allows mapping of Frame Relay FECN (Forward Explicit Congestion Notification) bit to
ATM EFCI (Explicit Forward Congestion Indicator) bit. The choices are

NO

MAP

FECN

and

MAP

FECN. The factory default setting is

NO

MAP

FECN

.

C

ONNECTION

(V35) > S

ETUP

> DLCI M

APPING

Use these menus to configure the DLCI mapping for the PVC from the T1 network interface to
the V.35 interface.

C

ONNECTION

(V35) > S

ETUP

> DLCI M

APPING

> M

AP

Displays the DLCI Map number and is used as an index for multiple listings. The first map
entry listed is 1, the next is 2, etc. All map numbers assigned will be sequential.

C

ONNECTION

(V35) > S

ETUP

> DLCI M

APPING

> A

CTIVE

Enables FR/ATM mapping and data passing between the V.35 FRFx connection and the
ATM PVC on the network interface. If set to

N

O

, data will not pass from the network to the

configured V.35 endpoint. By default, this field is set to

Y

ES

to allow data to pass as soon as

the connection is configured.

C

ONNECTION

(V35) > S

ETUP

> S

ETUP

> I

NTERFACE

The T1 interface is

ATM[0.0]

which represents the T1 physical and logical ports respectively.

This is an identifier for the system to document the T1 network end of the logical link
between the network port and the V.35 interface.
