Section 4 User Interface Guide Total Access 600 Series System Manual
178 © 2004 ADTRAN, Inc. 61200624L1-1B
3
Select I NTERFACES and press NTER >. Use the right arrow key to highlight the
S ETUP field for the T1 interface and press NTER >. Each virtual circuit on the
T1 interface defined in the PVC C ONFIG has a separate listing in the R OUTER
I NTERFACES table.
4 Set A CTIVE to Y ES to activate the virtual circuit.
5 Enter the appropriate VPI and VCI values.
6
Select the desired A DDRESS M ODE . Refer to Address Mode on page 122 for
more details.
7
Enter the Total Access 6XX L OCAL IP A DDRESS and corresponding IP
N ETMASK for the selected virtual circuit.
8 Enter the IP address for the next hop router in the F AR -E ND IP A DDRESS field.
9
For NAT configuration, refer to Appendix C. RFC1483 Quick Start (IP Routing
with NAT) on page 179.
10 Left arrow back to the main menu to save the changes.
Router Options – Setting the Default Gateway
Step Action
1 From the main menu, select R OUTER and press NTER >.
2 Use the right arrow key to highlight C ONFIG and press NTER >.
3
Select R OUTES and press NTER >. Set the D EFAULT G ATEWAY field to the
appropriate IP address.
4 Left arrow back to the main menu to save the changes.
Router Options – T1 Interface (L2 Protocol = ATM) (Continued)
