Total Access 600 Series System Manual Section 4 User Interface Guide
61200624L1-1B © 2004 ADTRAN, Inc. 153
2. Configuring the Layer 2 Protocol
For more details on the configuration parameters discussed in this section, refer to the following pages:
Layer 2 Frame Relay Protocol menus beginning on page 93
Layer 2 PPP Protocol menus beginning on page 91
Layer 2 Ethernet menus beginning on page 116
Ethernet Interface Setup Instructions
Most applications should not require a manual setup for the Ethernet interface. By
default, the Ethernet interface is configured to auto-detect the data rate (as either 10
or 100 Mbps). The following steps disable the auto-negotiation parameter and
manually configure the interface.
Step Action
1 From the main menu, select I NTERFACES .
2 Highlight the C ONFIG menu for the ETH interface and press NTER >.
3
Use the right arrow to select A UTONEGOTIATION and press NTER >. Use the
down arrow to choose OFF.
4 Select the D ATA R ATE field and specify either 10B ASE T or 100B ASE T.
5 Select the D UPLEX T YPE field and specify either H ALF D UPLEX or F ULL D UPLEX .
Layer 2 Protocol (FRE) Configuration – T1 Interface
Step Action
1 From the main menu, select L2 P ROTOCOL and press NTER >.
2
Use the arrow keys to select the P ROTOCOL field for the T1 interface. Press
NTER >. Select FRE from the list of available protocols.
3 Highlight the C ONFIG menu for the T1 interface and press NTER >.
4
Set the M AINTENANCE P ROTOCOL to A NNEX D (ANSI), A NNEX A (q933a), LMI, OR
S TATIC (no sig).
The M AINTENANCE P ROTOCOL should be set based on the Frame Relay switch.
5
Down arrow and press NTER > on DLCI M APPING . Press the right arrow key to
create an entry. To create additional entries, highlight the N UM field and press
the key. To delete an entry, highlight the N UM field for the entry to delete
and press the key.
6 Set A CTIVE to Y ES .
