Total Access 600 Series System Manual Section 4 User Interface Guide
61200624L1-1B © 2004 ADTRAN, Inc. 161
3. Verifying the Bridge Options
For more details on the configuration parameters discussed in this section, refer to the following pages:
Bridge menus beginning on page 117
4. Mapping the DS0s
For more details on the configuration parameters discussed in this section, refer to the following pages:
DS0 Map menus beginning on page 149
3
Set mode to B RIDGE A LL . Using this menu you also have the option to route
only IP packets and bridge all other data packets (R OUTE IP/B RIDGE O THER ) or
route all IP data packets on this connection (R OUTE IP). Refer to L2 Protocol
(ALL–ETH–802.3) > Config > Mode on page 116 for more details.
4 Left arrow back to the main menu to save the changes.
Bridge Options
Step Action
1 From the main menu, select B RIDGE and press NTER >.
2 Use the right arrow key to highlight C ONFIG and press NTER >.
3
Select I NTERFACES and press NTER >. Verify that the desired interface is
listed in this table.
4 Left arrow back to the B RIDGE > C ONFIG menu.
5
Select B RIDGE T ABLE and set the B RIDGE T ABLE A GING to the desired time (in
minutes) it takes an entry to age out of the Bridge table.
6 Left arrow back to the main menu to save the changes.
DS0 Mapping Instructions
Step Action
1 From the main menu, select DS0 M APS .
Layer 2 Protocol Configuration – Ethernet Interface (Continued)
